ETICS 10×10 Fiberglass Mesh High-performance fiberglass mesh designed for use in External Thermal Insulation Composite Systems (ETICS). The G-75 Standard is ideal for reinforcing base coat layers, preventing cracks, and ensuring long-term façade durability under mechanical and thermal stress. Lightweight yet strong fiberglass structure, Excellent resistance to mechanical stress and deformation, Uniform mesh openings for stable reinforcement, High flexibility for easy handling and embedding, Alkali-resistant coating for long-lasting durability, Prevents plaster cracking and surface scratches, Suitable for both renovation and new façade systems
Key Features
● Weight per unit area:** approx. 75 g/m²
● Mesh size:** approx. 10.0 (±1.0) mm × 10 (±1.0) mm
● Width:** 100 cm
● Length per roll:** 50 m
● Color:** White (standard)
● Packaging:** Shrink-wrapped rolls with label
The GATEX G-75 Standard fiberglass mesh must be embedded into a fresh base coat layer (2–3 mm) applied over insulation boards.
Installation steps:
● Unroll vertically from top to bottom.
● Press the mesh into the adhesive with a float or spatula.
● Maintain at least 10 cm overlaps between strips.
● Avoid folds, creases, or trapped air bubbles.
● Apply a second adhesive layer to fully cover the mesh.
Important:
Mesh overlaps must not coincide with insulation board joints.
At corners, windows, and door edges, insert diagonal reinforcement patches (approx. 20 × 30 cm) to strengthen stress-prone zones.
Material: Glass fibre with alkali-resistant, fibre-fixing coating
Length: 50 m (±1 %)
Width: 100 cm (±1 %)
Mesh size: 10.0 (±1.0) mm × 10.0 (±1.0) mm
Treated fabric weight: 75 g/m² (±5 %)
Organic content: 20 (±4 %) %
Average tensile strength (MD/CMD – warp/weft): ≥ 1200 N/5 cm / ≥ 1100 N/5 cm
Elongation (MD/CMD – warp/weft): 2.5–3.2 % / 2.5–3.2 %
Average tensile strength after ageing (MD/CMD): ≥ 900 N/5 cm / ≥ 900 N/5 cm
Elongation after ageing (MD/CMD): 1.6–2.0 % / 1.6–2.0 %
Reaction to fire: NPD
Certification: ETAG 004, TÜV Nord
Available colors: white, orange, yellow, red, blue, green
Standard roll size: 1 m × 50 m
Number of rolls per pallet: 35
